Komfort Line K-3 Smart&Quick

AXOR design engineers set themselves the goal of improving this line of hardware and making it even more versatile and convenient to use.

As a result, we got the updated Komfort Line K-3, which provides even higher assembly speed, but completely preserves its basic characteristics: comfortable operation, high quality and safety for end users.

0The main advantages of the updated line K-3 SMART & QUICK

  • The changed face plate provides a higher rigidity of the profile section, which increased its bending resistance, and the flawless appearance will satisfy even the most demanding consumers;


  • The increased linear dimensions of gears and stay arm allow PVC window producers use cutting tools (punching machines) for both straight and eccentric cuts when installing hardware;


  • Better connection of gears and stay arm with corner transmission due to location of the driving rod 0.25 mm lower;


  • Locking pins are located 0.25 mm lower, which will improve the operation of hardware set with micro ventilation and safety locking plates;


  • The presence of corner transmissions for eccentric cut will significantly facilitate the work of PVC window producers



K-3 SMART & QUICK – is the constant quality of AXOR Industry products, speed of assembly and versatility in using.

goods

0Application range

All window furniture in our catalogue is intended exclusively for the internal opening of windows and balcony doors.

The system K3 has been provided in such assemblies as, tilt and turn opening, single turn opening, single tilt opening and double sash opening as well.

goods

0Wrong operation safety device.

Provides comfortable closing of the window and prevents accidental opening.

goods

0Gradual ventilation.

It is possible to set staged ventilation, which allows you to adjust the desired ventilation mode, fixing the gap from 12 to 20 mm.

goods

0Micro-slit ventilation

Micro-slit ventilation allows you to open the window by 6 mm to ensure air access to the room without significant heat loss.

goods

0Sash lifter.

Prevents sagging of the sash during transportation or when the window is "closed".

goods

0Bushing in the lower hinge

Inside the lower hinge of the sash there is a bushing with a position lock made of high-strength polymer, which prevents the screw from unscrewing during transportation, or when the sash is turned during operation of the structure.

goods

0Upper hinge support pin

When connected to the stay arm hinge, it gets a hard and reliable fixation, thanks to a special sleeve made of high-strength polymer, which prevents involuntary disconnection in the "folded" and "open" positions.

goods

0Decorative covers

The choice of different colors of decorative covers on the hinge allows you to use accessories with different lamination options for the PVC window profile.

goods

0Stay arms

They ensure comfortable closing of the window due to the presence of a closer.

0The front bar has been changed

The changed front bar ensures a higher rigidity of the profile section, which has increased its resistance to bending, and the impeccable appearance will satisfy even the most demanding consumers.


0Increased linear dimensions

The increased linear dimensions of gears and stay arms allow windows and doors manufacturers to use cutting tools (guillotines) for both straight and eccentric cuts when installing hardware.

download

Komfort Line K-3 Smart&Quick. Technical catalogue for PVC profiles
