Smart Line S+

Smart line S+ hardware

Already in the basic configuration, this line contains a wrong operation safety device, locking plate integrated slit and 5 pressure points. This hardware can be completed to the highest level of burglary resistance - RC2 (WK2). At the same time, the design solutions implemented in Smart Line S+ make this hardware not only reliable in operation, but also allow to increase the speed and convenience of installation.

goods

2Burglar - resistant locking pins

Provide for the difficulties in case of the break in which is an important feature for the private houses and for the apartments located at top or ground floors of a building.

goods

2Anti-theft elements.

Anti-burglary locking plates make it difficult for intruders to break the window.

goods

2Stay arms

Use of the right-sided and left-sided stay arm with the increased to 20 mm. integrated sash latch mechanism operating threshold.

goods

2Pin in stay arms

The stay arm can be additionally complemented with the mushroom pin starting from the standard size of 600 mm.

goods

2Bottom hinge

Bearing pin of the bottom sash hinge (6x22 mm) is made of the high endurance steel and is integrated into the hinge housing which provides for the extra hinge strengths necessary for the use with the heavy sash.

goods

2Step-type angle locking

Step-type locking of pin bearing tilt angle prevents the shift of its position during the mounting process.

goods

2Lock pins in the hardware housing

Lock pins in the hardware housing that allow fixing all the hardware elements before the self-tapping screws are engaged and thus exclude elements’ shifting during the process.


goods

2Pin locking

Tilting of the bottom hinge bearing pin for 180° allows preventing the contact of the screwdriver bit lock with the pin bearing during the bottom self-tapping screw mounting.

goods

2Smart сorner connection

Simple and reliable connection of the stay arm with the middle lock with the help of the special clamp which also makes mounting more comfortable.

goods

2Optimization of the operations’ number

Straight cut excludes the necessity to shift the slider in the corner transmission and reliable element locking is provided with the help of the self-tapping screw.

goods

2Optimization of assembly

The stepped cut eliminates the need to move the slider on the angular gear, and the elements are reliably fixed using a self-tapping screw.

download

Smart Line S+ . Technical catalogue for PVC profiles

download

Smart Line S+– installation scheme
